Weight	N/A
Suitable for surface mounting	Yes
Dimming phase cut-off	Yes
Voltage type	AC/DC
Suitable for pedestal/floor mounting	Yes
With control gear	Yes
Suitable for number of lamps	2
Energy efficiency class of the provided exchangeable built-in lamp	E
Adjustability	Not adjustable
Surface protection	Lacquered
Nominal voltage	230 V
Type of control gear	LED operating device voltage-controlled
Protection class	I
Length	105 mm
Light sharing	Symmetric
Beam angle	Medium beam 21-40°
Degree of protection (IP)	IP44
Rated ambient temperature according to IEC62722-2-1	15 – 25 °C
Flickering value Pst LM	1
Height/depth	105 mm
Colour rendering index CRI	80-89
Max. system power	6 W
Light output	Direct/indirect
Luminous flux	660 lm
Width	105 mm
Power factor	0.9
Colour of light	White
Number of poles	3
Conductor cross section	2.5 mm²
Connectable conductor cross section	0.75 – 2.5 mm²
Connection type	Screwed terminal
No dim function	Yes
Colour consistency (McAdam ellipse)	SDCM3
Shape	Eckig
Light output	2-seitig
Height	< 700 mm
Suitable for wall mounting	Yes
Exchangeable control gear	Yes
Type of wiring	Ending
Beam angle adjustable	Continuously variable
Stroboscope effect value SVM	0.4
Max. number of luminaires per miniature circuit breaker B16	20
Max. number of luminaires per miniature circuit breaker C16	30
Unified Glare Ratio (UGR)	1
Style	Landhaus

Wall floodlight
